Smart AC Wallbox EV Charger (16A/32A): Compact & Reliable Charging for Home & Commercial Scenarios



AC chargers are the most widely used EV charging solution for daily home charging and light commercial scenarios. Our wall-mounted AC wallbox EV charger combines smart control, comprehensive safety protection and flexible customization, making it suitable for global markets and diverse application needs.





Product Overview



This AC wallbox EV charger supports 16A and 32A adjustable output, compatible with both single-phase 220V and three-phase 380V grids. With a compact wall-mounted design, it saves space and is easy to install, making it an ideal choice for home garages, residential communities, office buildings and small commercial parking lots.



Core Technical Specifications



Parameter	Details
Rated Current	16A / 32A adjustable
Rated Voltage	AC220V±15% / AC380V±15%
Basic Functions	4.3" display, Bluetooth & WiFi, RFID card, APP, Type A+AC 30mA RCD
Charging Connector	GBT / Type 2 / Type 1
Charging Cable	5M TPU cable
Insulation Resistance	>1000mΩ
Withstand Voltage	2000V
Contact Resistance	≤0.5mΩ
Operating Temperature	-30°C ~ +50°C
Optional Functions	Load balancing (single-phase CT / three-phase CT), OCPP & 4G, screenless version



Key Product Advantages



1. Multiple Smart Control Methods



The charger is equipped with a 4.3-inch display for intuitive status viewing, and supports multiple control modes including Bluetooth, WiFi, RFID card and mobile APP. Users can start/stop charging, view charging data and set charging schedules flexibly, meeting the usage habits of different user groups.



2. Comprehensive Electrical Safety Protection



Safety is the core priority of EV charging. This product has built-in Type A+AC 30mA residual current device (RCD), which can effectively detect AC and pulsating DC leakage and cut off power in time to prevent electric shock risks. It also has 2000V withstand voltage and >1000mΩ insulation resistance, fully complying with global electrical safety standards.



3. Wide Climate Adaptability



With an operating temperature range of -30°C to +50°C, the charger can operate stably in both cold winter regions and high-temperature areas. The 5M TPU charging cable features wear resistance, cold resistance and aging resistance, ensuring reliable long-term outdoor use.



4. Flexible Customization for Diverse Scenarios



To meet the needs of different projects, we provide a variety of optional function upgrades:

Load balancing: Suitable for multi-charger deployment in communities and commercial parking lots, avoiding grid overload

OCPP & 4G connectivity: Enables remote management and data monitoring for commercial operation scenarios

Screenless version: More cost-effective for scenarios that do not require on-site display operation

Typical Application Scenarios



Residential use: Private home garages, villa parking spaces

Community properties: Apartment buildings, residential shared parking lots

Commercial places: Office buildings, shopping malls, hotel parking lots

Fleet management: Enterprise fleets, logistics vehicle parking areas



Global Market Compatibility



The charger supports three mainstream charging interface standards: GBT, Type 1 and Type 2, covering the Chinese, European, American and Oceania markets. It can be customized according to local grid standards and certification requirements, supporting full OEM/ODM services including logo printing, packaging customization and function adjustment.



Summary



Our 16A/32A smart AC wallbox EV charger balances performance, safety and cost, and is a reliable choice for daily home charging and light commercial charging infrastructure deployment. Whether for individual users, property operators or engineering projects, it can provide stable and intelligent charging support.
