Dc Wall Box

The DC wall box is an innovative and practical solution for a growing EV market. Its fast charging, safety features, compatibility, and low maintenance features make it a versatile and reliable EV charging solution. So, if you're looking for a safe, efficient, and hassle-free charging solution for your electric vehicle, the DC wall box is the perfect choice.

Send Inquiry

Product Introduction

Product Instruction

The dc wall box plays a critical role in the rapidly evolving landscape of electric vehicles. As demand for faster and more efficient charging solutions grows, the importance of reliable direct current (DC) charging infrastructure becomes increasingly evident. Unlike traditional alternating current (AC) charging methods, which can be time-consuming, the dc wall box offers rapid charging capabilities that significantly reduce wait times while maintaining safety standards. Its compatibility with various types of EVs further highlights its significance as it caters to different needs without compromising performance quality.

product-800-899

Product Parameters

NO	Parameters	DC Wall Box
General Requirements
1	EV Charger Type	DC
2	Charger Capacity	20KW	30KW
3	Product Model NO.	ENC-DCB020A ANSI-DCB020A JIS-DCB020A	ENC-DCB030A ANSI-DCB030A JIS-DCB030A
4	Mounting	Wall-Mounted
Input Requirements
5	AC Supply System	Three-Phase, 5 Wire AC system
6	Nominal Input Voltage	AC380V±15%
7	Input Frequency	45-65Hz
Environmental Requirements
8	Ambient Temperature Range	-25 to 55°C
9	Ambient Humidity	5 to 95%
10	Storage Temperature	-40 to 70°C
Mechanical Requirements
11	IP Ratings	IP 54
12	Cooling	Air-cooled
Output Requirements
13	Number of Outputs	1
14	Type of Each Output	DC200-750V DC150-500V(JIS)
15	Single Output Max. Current	80 Amp	125 Amp
16	Power Factor	≥0.99(50% load above)
User Interface & Display Requirements
17	Display & Touch-Screen Size	7 InchesTouch Screen with Shell
18	User Authentication	Mobile Application or User Interface / QR Code/RFID Card /Password Login
19	Metering Information	Consumption Units
Communication Requirements
20	Communication between EVSE and Central Server	OCPP 1.6J Protocol (Optional)
21	Interface between Charger and CMS	Ethernet/3G/4G/WIFI (Optional)
Protection & Safety Requirements
22	Executive Standard	IEC 62196 2017, IEC 61851 2017, SAE J1772,CHAdeMO etc.
23	Safety Parameters	Over Current, Under Voltage, Residual Current, Surge Protection, Leakage Protection, Short Circuit, Over Temperature, etc.

Product Details

Firstly, rapid charging speed is one of our dc wall box charger most prominent characteristics - capable of delivering up to 30 kW of power and enabling EVs to reach 60% charge within just 30 minutes. This significantly reduces wait times compared to traditional AC charging methods, making it ideal for busy schedules and long journeys. Advanced user interfaces such as LCD screens and remote monitoring systems offer convenient control and real-time updates on charging status.

product-800-899

Secondly, compatibility across various types of EV models and brands further highlights its versatility and adaptability to different needs without compromising performance quality.

product-800-864

Safety Features

Safety measures are at the forefront of design considerations; built-in protection against overvoltage, undervoltage, short circuit, and temperature rise ensures safe operation even during extreme weather conditions.

product-800-637

Product Dimension

product-800-566

Customer Photos

The DC wall box is applicable to a wide range of EV charging scenarios, including home garages, commercial centers, public parking spaces, and other outdoor locations. So, whether you are at home or out and about, the DC wall box can quickly recharge your EV.

product-800-784
